De Condensator van de de Polyesterfilm 47nF Cl21X van Folienkondensator
Contact Persoon : Cecilia
Telefoonnummer : +86 18922170847
WhatsApp : +8618922170847
Min. bestelaantal : | 100Kpcs | Prijs : | USD 0.1/PCS |
---|---|---|---|
Verpakking Details : | Plastic Zak | Levertijd : | 14 dagen |
Betalingscondities : | T/T, Western Union, MoneyGram | Levering vermogen : | 1kkpcs/month |
Plaats van herkomst: | Guangzhou, China | Merknaam: | GDHY |
---|---|---|---|
Certificering: | ISO,SGS | Modelnummer: | CL21X 224J100V |
Gedetailleerde informatie |
|||
Merk: | GDHY | Codenummer: | L2240100-D-7,5-1R |
---|---|---|---|
Model: | CL21X 224J100V | Type: | Subminiature condensatoren |
Capaciteit: | 0.22uF | Voltage: | 63V/100V |
Afmeting (W*T*H): | 7.5*4.3*7.0mm | Hoogte: | 7.5mm |
Capaciteitstolerantie: | ±5% ~ ±10% | Materiaal: | Gemetalliseerde polyesterfilm |
Leverancierstype: | Originele Fabrikant | Inkapseling: | Epoxyharsdeklaag |
Hoog licht: | Subminiature Gemetalliseerde Polyestercondensator,Cl21x Gemetalliseerde Polyestercondensator,De Polyestercondensator van CL21X 224J100V |
Productomschrijving
SUBMINIATURE MEM/MEF-CONDENSATOREN CL21X 0,22ΜF63V/100VPITCH=7.5MM
Verwijzingsnormen | GB/T 7332 (CEI 60384-2) |
Klimaatcategorie | 40/85/21 |
Werkende Temperatuurwaaier | -40℃~85℃ Tmax 105℃ |
Capacitieve weerstand | 0.22μF |
Nominale spanning | 63V/100V |
Capaciteitstolerantie | ±5% (J); ±10% (K) |
Weersta voltage | Vt-t: 1.6UN 5S (at20 ±5℃) |
Dissipatiefactor | tgδ≤0.01 (20℃, 1KHz) |
tgδ≤0.015 (20℃, 10KHz) | |
Isolatieweerstand | C≤0.33μF R≥30000MΩ (at20℃ 100VDC 1Min) |
De maximumtijd van de Impulsstijging (dv/dt) | 25V/μS |
Beschikbaar informatieblad: CL21X.pdf
Toepassing
●Wijd gebruikt in Omleiding, Recht, het Koppelen, Impuls, Timingskringen, enz.
●Kan in medische apparaten worden gebruikt.
Eigenschappen
●Gemetalliseerde diëlektrische polyesterfilm
●Niet-inductieve windende structuur
●Epoxyharsdeklaag
●Vleklassen van looddraad aan elektrode direct
●Kleine grootte en lichtgewicht: 1000pcs in één zak, 40kpcs in één karton
Productbeeld
Productvorm
Opbrengslijn
Workshop&Equipment
Tentoonstelling
Certificatie
Verpakkingsmethode
